1008 / 1378
1008
TRANSPORT SUCKERS
1008
12
Prices in EURO - VAT not included
4499F
Apt for carrying plates with smooth surfaces such as glass, plastic, metal, etc. Made in die-cast
aluminium. With vacuometer for checking vacuum pressure. Central knob for vacuum adjustment.
High-sealing, rubber sucker, diameter 180mm.
For glass thickness up to 8mm and vertically lifted weights up to 150kg.
4499F
Each 156,00
vuoto
Spare suckers for Art. 4499 F.
O4499F
Each 66,80
vuoto
TRANSPORTSUCKERS
4499L
Product description as Art. 4499F
High-sealing, rubber sucker, diameter 200mm.
For glass thickness up to 10mm and vertically lifted weights up to 190kg.
4499L
Each 173,00
vuoto
Spare suckers for Art. 4499 L.
O4499L
Each 71,90
vuoto
TRANSPORTSUCKERS
4499LE
Apt for carrying plates with smooth, flat and lightly curved surfaces. Sturdy execution, pump
housing made of brass and piston made of synthetics. The vacuum is obtained through the
manual pump and can be controlled on the piston by means of a red indicator.
High-sealing, rubber sucker, diameter 150mm.
For vertically lifted weights up to 70kg. With 1 sucker.
4499LE
Each 202,00
vuoto
TRANSPORTSUCKERS
4499LF
Product description as Art. 4499LE
High-sealing, rubber sucker, diameter 200mm.
For vertically lifted weights up to 150kg. With 1 sucker.
4499LF
Each 245,00
vuoto
TRANSPORTSUCKERS
4499LR
new
With support and tie-rod for lifting with forklifts, hoists, cranes etc.
Suitable for transporting sheets with surfaces not only smooth and flat, but also slightly processed
and curved. Sturdy rubber-coated construction, pump body made of brass and piston made of
plastic. The vacuum is achieved through the activation of the manual pump and can be controlled
on the piston thanks to a red LED indicator.
Rubber suckers with high sealing, diameter mm 300.
For vertically lifted weights up to 250 kg
With 1 sucker.
4499LR
Each 808,00
vuoto
TRANSPORTSUCKERS
MOUNTING AND TRANSPORT SUCKERS
4499P
Prod. SCU
High-sealing, rubber suckers, diameter 120mm, swinging. Body in die-cast aluminium and handle
with groove for accommodating pulling straps with width 25mm. Particularly indicated for carrying,
assembling and removing crystals, curved glasses, body’s parts and for holding surfaces which
are not flat.
With 2 suckers, load 60kg.
4499P
Each 143,00
For assemblying belts see Art. 4489 A - 4489 E.
vuoto
Spare suckers for Art. 4499 P.
O4499P
Each 21,60
vuoto
MOUNTINGANDTRANSPORTSUCKERS
