TAPPING AND THREADING DEVICES

439

6

Prices in EURO - VAT not included

1465C

Threading device for Art. 1465 A.

Size

1

2

For thread by

M.

3 to 10 10 to 20

1465C

Each 267,00 339,00

vuoto

TAPPINGAND THREADINGDEVICES

TAPPING DEVICES

1465F

Prod. SCU

Type with tap holder quick change heads for quick tap change and axial compensation. For right/

left use. Suitable for drills and lathes with reverse gear. To be used in combination with quick

change heads Art. 1465 P (for Art. 1465 F 1)/ 1465 R (for Art.1465 F 2)/ 1465 S (for Art. 1465 F 3).

Size

1

2

3

Drive

C.M.

2

3

4

For metric threading machine M.

3-12

8-20 14-33

L body length

mm 42

67

105

De body Ø

mm 36

53

78

D heads drive Ø

mm 19

31

48

1465F

Each 307,00 370,00 913,00

vuoto

TAPPINGDEVICES

1465G

Rapid change cartridge model with a male holder for replacing the male section without having to

amend the axels. For right and left hand use. Suitable for drills and machines which can operate

in reverse mode. Can be used in combination with rapid-change cartridges in accordance with

Art. 1465 P and 1465 V.

Size

1

2

Drive

B12

B16

For metric threading machine M.

3-12

3-12

L body length

mm 56

65

De body Ø

mm 32

32

D heads drive Ø

mm 19

19

1465G

Each 175,00 191,00

vuoto

TAPPINGDEVICES

QUICK CHANGE ADAPTORS

1465P

1465R

1465S

Prod. SCU

In special steel, finely worked.

Suitable for tapping heads 1465F 1 and 1472 E 1-1A.

Dimensions (mm): De=30 D=19 L1=17 L2=4 L3=21,5 L=7.

Male drive Ø

mm

3,5

4

4,5

6

7

8

9

10

1465P

Each 41,50 41,50 41,50 41,50 41,50 41,50 41,50 41,50

vuoto

Product description as Art. 1465P

Suitable for tapping heads 1465 F 2 and 1472 E 2-2A.

Dimensions (mm): De=48 D=31 L1=30 L2=5 L3=35 L=11.

Male drive Ø

mm

7

8

9

10

11

12

14

1465R

Each 53,10 53,10 53,10 53,10 53,10 53,10 53,10

Male drive Ø

mm

16

18

1465R

Each 53,10 53,10

vuoto

Product description as Art. 1465P

Suitable for tapping heads 1465 F 3.

Dimensions (mm): De=70 D=48 L1=44 L2=6 L3=55,5 L=14.

Male drive Ø

mm

11

12

14

16

18

20

22

25

1465S

Each 171,00 171,00 171,00 171,00 171,00 171,00 171,00 171,00

vuoto

QUICKCHANGEADAPTORS

1465V

SAFETY CLUTCH model made from finely processed special steel.

Suitable for tap screws 1465 F 1 / 1465 G 1-2 e 1472 E 1-1A.

Dimensions (mm): De=32 D=19 L1=17 L2=25 L3=21,5 L=25.

Male drive Ø

mm

3,5

4

4,5

6

7

8

9

10

1465V

Each 110,00 110,00 110,00 110,00 110,00 110,00 110,00 110,00

vuoto

QUICKCHANGEADAPTORS
