442

TAPPING DEVICES

442

6

Prices in EURO - VAT not included

1477

High rotation precision, suitable for pillar drills.

With adjustable clutch. Automatic turn.

To be used with ER-DIN 6499/ISO 15488 collets.

Size

10

10A

16

16A

22

22A

For metric threading machines M.

3-10

3-10

8-16

8-16

10-22

10-22

Drive

CM 2

cyl. 25

CM 3

cyl. 25

CM 3

cyl. 32

Height L

mm 120

120

125

125

153

153

Height De

mm 67

67

75

75

90

90

Height F

mm 35

35

42

42

43

43

Elastic pliers for Art.

1561 GF 1561 GF 1561 GL 1561 GL 1561 GN 1561 GN

1477

Each 1.550,00 1.550,00 1.710,00 1.710,00 1.920,00 1.920,00

vuoto

TAPPINGDEVICES

1478

Very high precision, particularly suitable for CNC. Automatic turn, without adjustable clutch, for

high-speed use.

To be used with ER-DIN 6499/ISO 15488 collets.

Size

10

16

22

For metric threading machines M.

3-10

8-16

10-22

Height L

mm 120

125

153

Height De

mm 66

75

90

Elastic pliers for Art.

1561 GF 1561 GL 1561 GN

Cylindrical drive Ø

mm 25

25

32

1478

Each 1.330,00 1.420,00 2.050,00

vuoto

TAPPINGDEVICES

THREE-JAWS CHUCKS

1490G

1491G

Prod. SCU

LIGHT VERSION for portable rotation and hammer drills.

Red series

For Black & Decker, male shank 3/8x24.

For drill bits 0-10mm.

1490G

Each 18,80

vuoto

Product description as Art. 1490G

For Black & Decker, male shank 3/8x24.

For drill bits 1.5-13mm.

1491G

Each 24,40

vuoto

THREE-JAWSCHUCKS

1495G

Product description as Art. 1490G

Red series

For AEG, BOSCH, PEUGEOT, METABO,SKIL, etc.

Type

10

10A

10P

10R 10T 13A 13B

For tips Ø

mm 0-10

0-10

0-10

0-10

0-10 1.5-13 1.5-13

Drive

3/8-24 1/2-20 3/8-24 1/2-20

B12 3/8-24 1/2-20

Drive type

Thread.

Thread.

Thread.

Thread.

DIN Thread. Thread.

For rotation

Right

Right

Right+Left Right+Left

Right

Right

Right

1495G

Each 18,80

18,80

18,80

18,80 18,80 24,40 24,40

Type

13E

13L

13P

For tips Ø

mm 1.5-13 1.5-13 1.5-13

Drive

3/8-24 1/2-20

B12

Drive type

Thread.

Thread.

DIN

For rotation

Right+Left Right+Left

Right

1495G

Each 24,40

24,40

24,40

Art. 1495G 10P-10R-13E-13L are suitable for reverse rotation drills (Des.+ Sin.)

vuoto

THREE-JAWSCHUCKS

1500G

PROFESSIONAL VERSION for rotation and hammer drills.

Steel body, hardened and ground jaws.

Yellow series

Type

8

10

10A 10B 10C 10E 10F 13A 13B

For tips Ø mm 0.3-8 0.5-10 0.5-10 0.5-10 0.5-10 0.5-10 0.5-10 1.5-13 1.5-13

Drive

B12

B12

J2 3/8-24 1/2-20 3/8-24 1/2-20 B16

J2

Drive type

DIN DIN Jacobs Thread. Thread Thread.

Thread.

DIN Jacobs

For rotation

Right

Right

Right

Right

Right Right+Left Right+Left Right

Right

1500G Each 29,10 32,30 32,30 32,30 32,30 32,30 32,30 41,60 41,60

Type

13C 13CC 13D 13E 16

16/1

16A 16B 16C

For tips Ø mm 1.5-13 1.5-13 1.5-13 1.5-13 2.5-16 2.5-16 2.5-16 2.5-16 2.5-16

Drive

3/8-24 3/8-24 1/2-20 1/2-20 B16 B18

J6 1/2-20 1/2-20

Drive type

Thread. Thread. Thread. Thread.

DIN DIN Jacobs Thread. Thread.

For rotation

Right Right+Left Right Right+Left Right

Right

Right

Right Right+Left

1500G Each 41,60 41,60 41,60 41,60 55,70 55,70 55,70 55,70 55,70
