DRILL BITS FOR STONES AND WALLS

390

4

Prices in EURO - VAT not included

DRILL BITS FOR STONES AND WALLS

1331G

Prod. SCU

Standard type.

With standard HARD METAL tool bit for rotation and percussion.

Suitable for drilling stones, walls, tiles, paving tiles, ceramic surfaces, concrete, Klinker.

Chromatized finish.

For bits up to Ø 13mm, max connection Ø 10mm.

For bits Ø 14mm, connection Ø 13mm.

Type

4

5

5,5

6

6L 6,5

7

8

8L 8,5

9

10 10L 11

12

For bores Ø

mm 4

5

5,5

6

6

6,5

7

8

8

8,5

9

10

10

11

12

Overall length

mm 75

85

85 100 150 100 100 120 200 120 120 120 200 150 150

1331G

Each 1,34 1,36 1,38 1,40 2,08 1,52 1,56 1,76 2,70 1,62 2,12 2,28 3,04 3,22 3,22

Type

12L 13

14 14L 16 16L 20

For bores Ø

mm 12

13

14

14

16

16

20

Overall length

mm 200 150 150 200 150 200 160

1331G

Each 5,08 4,20 4,84 5,76 6,44 8,02 10,20

Size 8,5 running out of stock.

vuoto

DRILLBITSFORSTONESANDWALLS

1331GB

Professional type.

With standard HARD METAL tool bit for rotation and percussion.

Spiral bit with long engagement for better penetration. Suitable for drilling stones, walls, tiles,

paving tiles, ceramic surfaces, concrete, Klinker. Chromatized finish.

For bits up to Ø 18mm, max connection Ø 10mm

For bits Ø 20mm, connection Ø 13mm.

Type

3

4

5

5L 5,5

6

6L 6,5

7

8

8L

9

10 10L 11

For bores Ø

mm 3

4

5

5

5,5

6

6

6,5

7

8

8

9

10

10

11

Overall length

mm 70

75

85 150 85 100 150 100 100 120 200 120 120 200 150

1331GB

Each 1,68 1,62 1,66 2,48 1,74 1,74 2,70 1,84 2,06 2,34 3,66 2,82 3,18 4,84 4,40

Type

12

13

14

15

16

18

20

For bores Ø

mm 12

13

14

15

16

18

20

Overall length

mm 150 150 150 150 150 160 160

1331GB

Each 4,84 5,90 6,38 8,06 8,06 9,86 11,10

When stocks are depleted, we will provide the drills sandblasted instead of chromated.

vuoto

DRILLBITSFORSTONESANDWALLS

1332G

Professional type.

With standard HARD METAL tool bit for rotation and percussion.

High-power spiral bit for better penetration. Suitable also for battery drills. For drilling stones,

walls, tiles, paving tiles, ceramic surfaces, concrete, Klinker. Chromatized finish.

For bits up to Ø 16mm, max connection Ø 10mm.

For bits Ø 18 and 20mm, connection Ø 12mm.

Type

4

5

5L 6

6L 7

8

8L 10 10L 12 13 14 16 18 20

For bores Ø

mm 4

5

5

6

6

7

8

8

10 10 12 13 14 16 18 20

Overall length

mm 75 85 150 100 150 100 120 200 120 200 150 150 150 150 160 160

1332G

Each 1,42 1,48 2,66 1,72 2,78 2,32 2,32 5,66 3,02 6,56 4,16 6,96 7,20 9,98 12,90 16,40

vuoto

DRILLBITSFORSTONESANDWALLS

DRILL BITS FOR HARD STONES AND WALLS

1332GB

Prod. SCU

Professional/industrial type.

With HARD METAL tool bit for rotation and percussion.

With strengthened cutting edge and heavy-duty bearing. Made of forged and hardened bright

steel. Strengthened trapezoidal twist drill to ensure a very high material removal rate. For drilling

very hard stones such as granite, basalt, porphyry and also compressed concrete of great

hardness. Suitable for drilling metals with strength up to 180 kg/mm2 , to be used on static drills.

For bits up to Ø 18mm, max connection Ø 10mm.

For bits Ø higher than 18mm, connection Ø 13mm.

Type

3

4

4,5*

5

5L 5,5 5,5L*

6

6L 6,5 6,5L*

7

7L*

8

8L

For bores Ø

mm 3

4

4,5

5

5

5,5 5,5

6

6

6,5 6,5

7

7

8

8

Overall length

mm 85

85

85

95 150 95 150 100 150 100 150 100 150 120 200

1332GB

Each 3,64 3,76 3,72 3,84 7,42 3,86 7,12 3,94 7,96 4,00 8,72 4,14 8,62 5,00 9,68

Type

9

10 10L 11*

12 12L 13*

14 14L*

15*

16

18

20 22*

25*

For bores Ø

mm 9

10

10

11

12

12

13

14

14

15

16

18

20

22

25

Overall length

mm 120 120 200 150 150 220 150 150 260 150 150 160 160 160 160

1332GB

Each 5,98 6,82 11,70 8,04 10,20 15,30 13,10 15,10 18,60 18,10 20,70 24,40 27,60 37,40 46,10

* Sizes running out of stock.

vuoto

DRILLBITSFORHARDSTONESANDWALLS
