SPECIAL DRILL TIPS FOR PORCELAIN STONEWARE
4
393
Prices in EURO - VAT not included
SPECIAL DRILL TIPS FOR PORCELAIN STONEWARE
1334GZ
Prod. SCU
Light and handy, it ensures a proper bit cooling during hole drilling by using water or coolant. To
be installed on the drill collar. Provided with nozzle adjustable by means of flexible pipe and cock
to ensure precision and avoid waste. Equipped with additional air valve to stop the flow, if
necessary, without operating the cock.
Especially useful to drill tiles on vertical walls. Necessary when using bits Art. 1334 GC, that
require a great cooling capacity.
1334GZ
Each 16,50
vuoto
SPECIALDRILLTIPSFORPORCELAINSTONEWARE
DRILL BITS FOR STONES AND WALLS - LONG TYPE
1335G
Prod. SCU
With HARD METAL tool bit, for rotation and percussion.
. Suitable for stones, concrete, wall. marble and ceramic surfaces.
Chromatized finish.
Type
8
8L
10
10L
12
12L
14
14L
16
16L
18
18L
For bores Ø
mm 8
8
10
10
12
12
14
14
16
16
18
18
Useful length
mm 350
550
350
550
350
550
350
550
350
550
350
550
Overall length
mm 400
600
400
600
400
600
400
600
400
600
400
600
Drive Ø
mm 7,3 cyl.
7,3 cyl.
9,3 cyl.
9,3 cyl.
10
hexag.
10
hexag.
10
hexag.
10
hexag.
10
hexag.
10
hexag.
10
hexag.
10
hexag.
1335G
Each 6,78
10,70
8,64
12,90 10,40 15,10 13,10 17,40 15,10 19,40 17,80 24,40
Type
20
20L
22
22L
25
25L
28
28L
30
30L
32
35
For bores Ø
mm 20
20
22
22
25
25
28
28
30
30
32
35
Useful length
mm 350
550
350
550
350
550
350
550
350
550
350
350
Overall length
mm 400
600
400
600
400
600
400
600
400
600
400
400
Drive Ø
mm 10
hexag.
10
hexag.
12
hexag.
12
hexag.
12
hexag.
12
hexag.
12
hexag.
12
hexag.
12
hexag.
12
hexag.
12
hexag.
12
hexag.
1335G
Each 20,80 27,10 25,40 31,90 31,80 40,00 39,80 47,70 42,80 51,60 44,00 55,60
Type from 18 to 20L may be used with extension Art. 1336 GT.
Type from 22 to 35 may be used with extension Art. 1336 GV.
Sizes 28, 28L, 30, 30L, 32 and 35 running out of stock.
vuoto
DRILLBITSFORSTONESANDWALLS - LONGTYPE
EXTENSIONS
1336GT
1336GV
Prod. SCU
Extensions for drill bits 1335 G type 18 to 20L. with 10mm hexagonal shank.
Working length 370mm.
1336GT
Each 45,90
vuoto
Extensions for drill bits 1335 G type 22 to 35 with 12mm hexagonal shank and for core bits
1337GN with shank 1337 GP/1337 GP 1.
Working length 370 mm.
1336GV
Each 47,20
vuoto
EXTENSIONS
ROTARY CORE BITS FOR STONES AND WALLS
1337GN
Prod. SCU
With HARD METAL tool bit, for rotation and percussion.
. Suitable for stones,rocks, concrete conglomerates.
Hole depth: 50mm. Internal thread M16.
Core bit only.
Nibbling machine crown Ø mm
25
30
35
40
50
68
80
1337GN
Each 49,80 49,80 52,50 52,50 55,90 68,80 79,70
Nibbling machine crown Ø mm
90
100
1337GN
Each 92,10 150,00
vuoto
DRILLBITSFORHARDSTONESANDWALLS
