391

MULTI-PURPOSE DRILL BITS

4

391

Prices in EURO - VAT not included

MULTI-PURPOSE DRILL BITS

1333GA

Prod. SCU

With HARD METAL tool bit. Rotation-only type.

The good sharpening of the cutting edges ensures accurate spot-drilling, reduced pressure,

quick drilling and long-life bit. Asymmetric twist drill for very accurate material removal.

Suitable for drilling walls, tiles, ceramic surfaces, Klinker, Eternit, laminated plastic, marble,

aluminium, iron and wood. Made of bright steel.

For bits up to Ø 12mm, max connection Ø 10mm.

Type

4

5

6

6L

7

8

8L 10 10L 12

For bores Ø

mm 4

5

6

6

7

8

8

10

10

12

Overall length

mm 75

85 100 150 100 120 200 120 200 150

1333GA

Each 5,98 6,40 7,02 10,40 7,94 8,72 12,90 11,50 16,50 15,70

vuoto

MULTI-PURPOSEDRILLBITS

PILOT DRILL BITS

1334G

Prod. SCU

With HARD METAL tool bit and center drill.

Rotation-only type. Very high efficiency due to the shape of the cutting edge. Made of bright

steel, with corrosion-proofing protection.

For non-metallic materials. Suitable for walls (except for reinforced concrete), marble, concrete,

plywood, laminated plastic, ceramic surfaces, glass, porcelain and similar.

Max connection Ø 10 mm.

For bores Ø

mm

3

4

5

6

8

10

12

Overall length

mm 85

85

95

100

120

120

150

1334G

Each 5,58

5,38

7,34

7,60

8,42 10,70 12,70

vuoto

PILOTDRILLBITS

UNIVERSAL DRILL BITS

1334GB

Prod. SCU

With HARD METAL tool bit and diamond-shaped cutting edge. Strengthened trapezoidal twist

drill, for a very high material removal rate.

Standard type for rotation and percussion. For drilling very hard stones such as granite, basalt,

porphyry and also compressed concrete of great hardness.

For metallic and non-metallic materials, marble, plywood, laminated plastic, ceramic surfaces,

glass, porcelain and similar. Made of bright steel.

Max connection Ø 10 mm.

Type

3

4

5

5L 5,5

6

6L 6,5

8

8L 10 10L 12 12L 14

For bores Ø

mm 3

4

5

5

5,5

6

6

6,5

8

8

10

10

12

12

14

Overall length

mm 70

85

85 150 85 100 150 100 120 200 120 200 150 220 260

1334GB

Each 4,54 5,08 5,04 7,32 4,94 4,90 7,86 5,14 5,84 9,68 6,98 12,90 11,20 16,80 21,10

For the same type with SDS-plus see Art. 1340 GL.

vuoto

UNIVERSALDRILLBITS

SPECIAL DRILL TIPS FOR PORCELAIN STONEWARE

1334GC

Prod. SCU

Diamond-edged type for drilling porcelain stoneware tiles. If used according to the indications

provided, several drills can be made even on hard and more abrasive tiles.

Connection Ø 10mm. Total length 55mm.

For bores Ø

mm

5

6

7

8

10

1334GC

Each 19,40 20,50 21,70 22,80 24,10

vuoto

DRILLBITSFORHARDSTONESANDWALLS
